Description
Installation
1. Disconnect "ground" cable from the battery!
2. Settle DBS on the car body near the battery.
3. Connect it according to the scheme (Pict. 1), using cable not less than 25mm² for Battery1, Battery2 and 0,5mm² for the others.
4. Forced OFF is possible with the help of the switch or fixation button ""start".
1. Disconnect "ground" cable from the battery!
2. Settle DBS on the car body near the battery.
3. Connect it according to the scheme (Pict. 1), using cable not less than 25mm² for Battery1, Battery2 and 0,5mm² for the others.
4. Forced OFF is possible with the help of the switch or fixation button ""start".
Characteristics
| Nominal Voltage, V | 12 |
| Maximum Current, А | 300 |
| Nominal Current, А | 200 |
| Supply Current, mА | 1,5 |
| Connective Clamps | М8 |
| OFF Voltage, V | 12,8 |
| ON Voltage, V | 13,2 |
| ON/OFF Delay, s | 6 |
| Weight, g | 310 |
| Dimensions, mm | 101х50х44 |
